March 16, 2007
|
|
True color image of M106 spiral galaxy, obtained on 2007 March 16 with 60-cm, f/3.3 Deltagraph
telescope, BVRW filters and 1k x 1k thinned CCD. Exposure times were 3x180s B, 3x120s R, 3x120s V and 3x30s W.
The luminance image was composed by adding BVRW exposures (total 1330 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
June 3, 2005
|
|
True color image of M11 open cluster, obtained on 2005 June 3 with 60-cm, f/3.3 Deltagraph
telescope, BVR filters and 1k x 1k thinned CCD. Exposure times were 120s B, 60s R and 60s V.
The luminance image was composed by adding BVR exposures (total 240 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
March 17, 2005
|
|
True color image of M27 planetary nebula, obtained on 2005 March 17 with 60-cm, f/3.3 Deltagraph
telescope, BVR filters and 1k x 1k thinned CCD. Exposure times were 60s B, 60s R and 60s V.
The luminance image was composed by adding BVR exposures (total 180 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
January 17, 2005
|
|
True color image of M51 spiral galaxy, obtained on 2005 January 17 with 60-cm, f/3.3 Deltagraph
telescope, BVR filters and 1k x 1k thinned CCD. Exposure times were 180s B, 120s R and 120s V.
The luminance image was composed by adding BVR exposures (total 420 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
January 14, 2005
|
|
True color image of M42 nebula, obtained on 2005 January 14 with 60-cm, f/3.3 Deltagraph
telescope, BVRW filters and 1k x 1k thinned CCD. Exposure times were 3x10s+3x20s R, 3x10s+3x20s V,
3x30s+2x60s B, 3x2s W. The luminance image was composed by adding all BVRW exposures (total 396 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
January 13, 2005
|
|
True color image of M13 globular cluster obtained on 2005 January 13 with 60-cm, f/3.3 Deltagraph
telescope, BVRW filters and 1k x 1k thinned CCD. Exposure times were 3x120,2x60,2x60,2x15 seconds.
The luminance image was composed by adding all BVRW exposures (total 630 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
January 12, 2005
|
|
True color image of M3 globular cluster obtained on 2005 January 12 with 60-cm, f/3.3 Deltagraph
telescope, BVRW filters and 1k x 1k thinned CCD. Exposure times were 120,60,60,15 seconds.
The luminance image was composed by adding BVRW exposures (total 255 seconds).
The image scale is 2.49 arc sec/pixel.
Copyright © 2007 by J. Zakrajek and H. Miku, Črni Vrh Observatory.
|
|
February 10, 2004
|
|
False color image of newly discovered infrared source IRAS_05436-0007 in Orion was obtained on 2004 February 10 (20h23 UT) with 60-cm, f/3.3 Deltagraph
telescope and CCD. Image was made by stacking 4 frames with total exposure time of 750 seconds. High resolution image (below) cover the area of
62' x 62' with resolution of 0.9"/pixel. Copyright © 2004 by H. Mikuž and B. Dintinjana, Črni Vrh Observatory.
 High resolution image (6.3 Mb)
|
|
April 24, 2003
|
|
True color image of M104 galaxy, obtained on 2003 April 24 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
High resolution image (1196x1180)
|
|
True color image of M105 galaxy group in Leo, obtained on 2003 April 24 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
|
|
True color image of M88 galaxy, obtained on 2003 April 24 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
|
|
True color image of NGC 4565 galaxy in Coma Berenices, obtained on 2003 April 24 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
|
|
April 1, 2003
|
|
False color image of M3 globular cluster, obtained on 2003 April 1 with 60-cm, f/3.3 Deltagraph
telescope, R filter and 1k x 1k thinned CCD. Exposure time was 60 seconds. The image scale is 2.49 arc sec/pixel.
Copyright © 2003 by B. Dintinjana and H. Mikuž, Črni Vrh Observatory.
|
|
March 24, 2003
|
|
False color image of NGC 1499 (California Nebula) in Perseus, obtained on 2003 March 24 with 60-cm, f/3.3 Deltagraph
telescope, R filter and 1k x 1k thinned CCD. Image is a mosaic of 12 individual frames, exposed for 60 seconds each.
Copyright © 2003 by B. Dintinjana, Črni Vrh Observatory.
High resolution image (3680x2800)
|
|
March 23, 2003
|
|
True color image of M101 spiral galaxy, obtained on 2003 March 23 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
High resolution image (2048x2048)
|
|
True color image of M51 spiral galaxy, obtained on 2003 March 23 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
High resolution image (2048x2048)
|
|
True color image of M65 (left) and M66 (right) group in Leo, obtained on 2003 March 23 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
|
|
True color image of M81 spiral galaxy, obtained on 2003 March 23 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
High resolution image (2048x2048)
|
|
True color image of M87 galaxy group, obtained on 2003 March 23 with 60-cm, f/3.3 Deltagraph
telescope, BVR photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R filter images. Copyright © 2003 by H. Mikuž and Jure Zakrajšek, Črni Vrh Observatory.
High resolution image (2048x2048)
|
|
February 25, 2003
|
|
False color image of IC 434 (Horsehead Nebula) in Orion, obtained on 2003 February 25 with 60-cm, f/3.3 Deltagraph
telescope, R filter and 1k x 1k thinned CCD. Exposure time was 120 seconds. The image scale is 2.49 arc sec/pixel.
Copyright © 2003 by H. Mikuž, Črni Vrh Observatory.
|
|
January 29, 2003
|
|
True color (LRGB) image of comet C/2002 V1 (NEAT), obtained on 2003 January 29 (18h44-18h57UT)
with 60-cm, f/3.3 Deltagraph telescope, photometric filters and CCD. Image is a composite of 3x60s B, 3x60s V and 3x60s R
images added together. The light image (L) was made by adding all 9 images. Image scale is 2.49 arc sec/pixel.
Copyright © 2003 by B. Dintinjana and J. Skvarč, Črni Vrh Observatory.
|
|
October 28, 2002
|
|
True color image of M33 spiral galaxy, obtained on 2002 October 28 with 60-cm, f/3.3 Deltagraph
telescope, photometric filters and 1k x 1k thinned CCD. Image is a composition of 180 sec B, 120sec
V and 120 sec R images added together with Gimp image processing software. The FOV is 42 x 42 arc
minutes with image scale 2.49 arc sec/pixel. Copyright © 2002 by B. Dintinjana and H. Mikuž, Črni Vrh Observatory.
|
|
September 16, 2002
|
|
False color image of M33 spiral galaxy, obtained on 2002 September 16.014UT with 60-cm, f/3.3 Deltagraph
telescope, V filter and 1k x 1k thinned CCD. Exposure time was 120 seconds. The FOV is 42 x 42 arc
minutes with image scale 2.49 arc sec/pixel. Copyright © 2002 by DELTA60 team, Črni Vrh Observatory.
|
|
|
|
False color image of M110 satellite galaxy, obtained on 2002 September 16.018UT with 60-cm, f/3.3
Deltagraph telescope, V filter and 1k x 1k thinned CCD. Exposure time was 120 seconds. The FOV is 42 x 42 arc
minutes with image scale 2.49 arc sec/pixel. Spiral arms in the right lower corner belong to M31. Copyright © 2002 by
DELTA60 team, Črni Vrh Observatory.
|
|
|
|
